Stable named local URLs as BEAM infrastructure: a loopback reverse proxy, a route registry, and a zero-dependency client, shaped so host applications can depend on it without cost or ceremony.

1. The problem

Local dev servers live on ports; ports collide, wander between runs, and read like noise (localhost:5173 means nothing). portless solved this for the npm world with named .localhost URLs, but its shape — global npm install, self-elevation to bind 443, a locally trusted root CA, and per-framework --port flag injection — is both a large supply-chain surface and a moving compatibility target.

2. Principles

  • Register, don't wrap. Wrapping child processes is the BEAM's weakest cross-platform spot (no PTY on Windows, awkward signal forwarding) and flag injection is a compatibility treadmill. Apps start themselves and register {name, port}; the daemon only proxies.
  • The library must cost nothing. Cherrypicker (the client) uses only the standard library (:httpc, JSON), so a host app taking the dependency adds no runtime processes, no pool, no supervision — and never opens a port as a side effect of being in a deps list.
  • Loopback is the trust boundary. The daemon binds loopback-facing ports and .localhost never resolves off-machine. The control API is therefore as trusted as any local dev server — no auth theatre in phase 1.
  • Honest degradation. No daemon → {:error, :no_daemon} → callers print their port URL as ever. A stale state file costs one failed connect, never a wrong answer.

3. Architecture

~/.cherrypicker/daemon.json         (state file: the bound proxy port)
        ▲ write on start / remove on stop        ▼ read by clients
┌────────────────────── Cherrypicker.Daemon ─────────────────────┐
│ Routes (GenServer + ETS)   Finch pool   Bandit :80/:N          │
│                                            │                   │
│   Host: cherrypicker.localhost → Control (REST, JSON)          │
│   Host: <name>.localhost       → Proxy → 127.0.0.1:<port>      │
└────────────────────────────────────────────────────────────────┘
      ▲ PUT /routes/:name          ▲ GET http://mysite.localhost
      │ CLI verbs / library client │ browser / curl / agent
  • Routing is the Host header. <name>.localhost[:port] → name; the reserved name cherrypicker serves the control API on the same listener, so there is exactly one port and http://cherrypicker.localhost is a future human dashboard for free.
  • Streaming both ways. Responses are forwarded chunk-by-chunk (Finch.stream/5 with an infinite receive timeout), so SSE — dev-server live reload — stays live. A client that disconnects mid-stream throws out of the stream fold, which is what stops the upstream pull.
  • X-Forwarded-Host carries the raw named host so upstreams can emit browser-correct links; hop-by-hop headers are stripped per RFC 9110.
  • Ephemeral-capable. port: 0 binds a free port and the state file advertises it — tests and multi-instance setups need no coordination.

4. Phases

Phase 1 (built): daemon, registry, streaming HTTP proxy, control API, state-file discovery, stdlib client, escript CLI with --json envelopes.

Phase 2 — TLS, opt-in: cherrypicker trust generates a local CA (the x509 library over OTP :public_key) and installs it via the platform's own tool (certutil, security add-trusted-cert, distro trust stores); the proxy then terminates HTTPS with per-name leaf certs minted on demand. Documented mkcert interop as the escape hatch. Never a silent side effect of any other verb.

Phase 3 — polish: WebSocket passthrough (Bandit upgrade + Mint WS), background daemonization per platform, route persistence across restarts, Burrito binaries with checksums + provenance (the cherry release pipeline, reused), cherrypicker.localhost dashboard page.

5. Non-goals

Production serving, TLS termination for deployed sites, tunneling to the public internet, and process management of the apps behind routes.
